Long cycle life and 5000 cycles
Lithium iron phosphate high stability cell, heat out of control, no fire
Multi layer BMS system ensures the reliability of lithium battery layer by layer
Efficient early warning, over temperature early warning report, ensure safety
Efficient
High energy density, saving 70% floor area compared with lead acid
Intelligent battery management system saves 80% of daily operation and maintenance costs
Simple
Active current sharing technology supports the mixing of new and old batteries, and the capacity expansion is simple
Intelligent voltage sharing control, support the number of lithium module differentiation and hybrid
DET LifePO4 Home Energy Storage Series |
||||
Model/ Parameters |
DETPW-48600 |
DETPW-48800 |
DETPW-48900 |
DETPW-481200 |
Basic | ||||
Normal Voltage [V] | 48/51.2 | 48/51.2 | 48/51.2 | 48/51.2 |
Normal Capacity [Ah] | 600 | 800 | 900 | 1200 |
Operating Voltage [V] | 45~56 | 45~56 | 45~56 | 45~56 |
Rated energy [kWh] | 28 | 38.4 | 43.2 | 57.6 |
Battery Type | Li-on(LFP) | Li-on(LFP) | Li-on(LFP) | Li-on(LFP) |
Ah Efficiency [%] | 99.5 | 99.5 | 99.5 | 99.5 |
Wh Efficiency [%] | 96 | 96 | 96 | 96 |
Standard Power [kW] | 28 | 38.4 | 43.2 | 57.6 |
Recommended Charging current [A] | 30 | 50 | 50 | 50 |
Maximum Discharging current [A] | 600 | 800 | 900 | 1200 |
Dimension(L*W*H) [mm] | 800*650*750 | 800*650*980 | 800*650*1200 | 800*650*1500 |
Weight [Kg] | 45 | 53 | 89 | |
Communication | ||||
Battery to Inverter | RS485/CAN 2.0 | RS485/CAN 2.0 | RS485/CAN 2.0 | RS485/CAN 2.0 |
Battery to Battery/BMS | RS485 | RS485 | RS485 | RS485 |
WIFI Application | Optional | Optional | Optional | Optional |
Capacity Indicator | 4LED and Central display (Intelligent Display) | |||
Switch ON/OFF | In Cabinet | In Cabinet | In Cabinet | In Cabinet |
Environment | ||||
Operating Temperature [℃] | -10 to 55 | -10 to 55 | -10 to 55 | -10 to 55 |
Relative Humidity [%] | 5 to 95 | 5 to 95 | 5 to 95 | 5 to 95 |
Altitude [m] | Below 2000 | Below 2000 | Below 2000 | Below 2000 |
Cycle Life [80% DOD] | > 5000 Cycles | > 5000 Cycles | > 5000 Cycles | > 5000 Cycles |
Parallel Connection | Max.64pcs | Max.64pcs | Max.64pcs | Max.64pcs |
Warranty [Year] | 5~8 | 5~8 | 5~8 | 5~8 |
