DET LifePO4 Home Energy Storage Series 1 |
||||
| Model/ Parameters |
DETPW-51.2600 |
DETPW-51.2800 |
DETPW-51.2900 |
DETPW-51.21200 |
| Basic | ||||
| Normal Voltage [V] | 48/51.2 | 48/51.2 | 48/51.2 | 48/51.2 |
| Normal Capacity [Ah] | 600 | 800 | 900 | 1200 |
| Operating Voltage [V] | 45~56 | 45~56 | 45~56 | 45~56 |
| Rated energy [kWh] | 28 | 38.4 | 43.2 | 57.6 |
| Battery Type | Li-on（LFP） | Li-on（LFP） | Li-on（LFP） | Li-on（LFP） |
| Ah Efficiency [%] | 99.5 | 99.5 | 99.5 | 99.5 |
| Wh Efficiency [%] | 96 | 96 | 96 | 96 |
| Standard Power [kW] | 28 | 38.4 | 43.2 | 57.6 |
| Recommended Charging current [A] | 30 | 50 | 50 | 50 |
| Maximum Discharging current [A] | 600 | 800 | 900 | 1200 |
| Dimension(L*W*H) [mm] | 800*650*750 | 800*650*980 | 800*650*1200 | 800*650*1500 |
| Weight [Kg] | 320 | 360 | 410 | 450 |
| AC Output | ||||
| Normal Voltage [V] | 220~230 | 220~230 | 220~230 | 220~230 |
| AC charging | 220~230 | 220~230 | 220~230 | 220~230 |
| Communication port | RS485/232 | RS485/232 | RS485/232 | RS485/232 |
| Communication | ||||
| Battery to Inverter | RS485/CAN 2.0 | RS485/CAN 2.0 | RS485/CAN 2.0 | RS485/CAN 2.0 |
| Battery to Battery/BMS | RS485 | RS485 | RS485 | RS485 |
| WIFI Application | Optional | Optional | Optional | Optional |
| Capacity Indicator | 4LED and Central display (Intelligent Display) | |||
| Switch ON/OFF | In Cabinet | In Cabinet | In Cabinet | In Cabinet |
| Environment | ||||
| Operating Temperature [℃] | -10 to 55 | -10 to 55 | -10 to 55 | -10 to 55 |
| Relative Humidity [%] | 5 to 95 | 5 to 95 | 5 to 95 | 5 to 95 |
| Altitude [m] | Below 2000 | Below 2000 | Below 2000 | Below 2000 |
| Cycle Life [80% DOD] | > 5000 Cycles | > 5000 Cycles | > 5000 Cycles | > 5000 Cycles |
| Parallel Connection | Max.8pcs | Max.8pcs | Max.8pcs | Max.8pcs |
| Warranty [Year] | 5~8 | 5~8 | 5~8 | 5~8 |
|
DET LifePO4 Home Energy Storage Series |
||||
| Model/ Parameters |
DETPW-51.2600 |
DETPW-51.2800 |
DETPW-51.2900 |
DETPW-51.21200 |
| Basic | ||||
| Normal Voltage [V] | 48/51.2 | 48/51.2 | 48/51.2 | 48/51.2 |
| Normal Capacity [Ah] | 600 | 800 | 900 | 1200 |
| Operating Voltage [V] | 45~56 | 45~56 | 45~56 | 45~56 |
| Rated energy [kWh] | 28 | 38.4 | 43.2 | 57.6 |
| Battery Type | Li-on（LFP） | Li-on（LFP） | Li-on（LFP） | Li-on（LFP） |
| Ah Efficiency [%] | 99.5 | 99.5 | 99.5 | 99.5 |
| Wh Efficiency [%] | 96 | 96 | 96 | 96 |
| Standard Power [kW] | 28 | 38.4 | 43.2 | 57.6 |
| Recommended Charging current [A] | 30 | 50 | 50 | 50 |
| Maximum Discharging current [A] | 600 | 800 | 900 | 1200 |
| Dimension(L*W*H) [mm] | 800*650*750 | 800*650*980 | 800*650*1200 | 800*650*1500 |
| Weight [Kg] | 320 | 360 | 410 | 450 |
| AC Output | ||||
| Normal Voltage [V] | 220~230 | 220~230 | 220~230 | 220~230 |
| AC charging | 220~230 | 220~230 | 220~230 | 220~230 |
| Communication port | RS485/232 | RS485/232 | RS485/232 | RS485/232 |
| Communication | ||||
| Battery to Inverter | RS485/CAN 2.0 | RS485/CAN 2.0 | RS485/CAN 2.0 | RS485/CAN 2.0 |
| Battery to Battery/BMS | RS485 | RS485 | RS485 | RS485 |
| WIFI Application | Optional | Optional | Optional | Optional |
| Capacity Indicator | 4LED and Central display (Intelligent Display) | |||
| Switch ON/OFF | In Cabinet | In Cabinet | In Cabinet | In Cabinet |
| Environment | ||||
| Operating Temperature [℃] | -10 to 55 | -10 to 55 | -10 to 55 | -10 to 55 |
| Relative Humidity [%] | 5 to 95 | 5 to 95 | 5 to 95 | 5 to 95 |
| Altitude [m] | Below 2000 | Below 2000 | Below 2000 | Below 2000 |
| Cycle Life [80% DOD] | > 5000 Cycles | > 5000 Cycles | > 5000 Cycles | > 5000 Cycles |
| Parallel Connection | Max.8pcs | Max.8pcs | Max.8pcs | Max.8pcs |
| Warranty [Year] | 5~8 | 5~8 | 5~8 | 5~8 |
