Construction:
Reliable
- Long cycle life and 5000 cycles
- Lithium iron phosphate high stability cell, heat out of control, no fire
- Multi layer BMS system ensures the reliability of lithium battery layer by layer
- Efficient early warning, over temperature early warning report, ensure safety
Efficient
- High energy density, saving 70% floor area compared with lead acid
- Intelligent battery management system saves 80% of daily operation and maintenance costs
Simple
- Active current sharing technology supports the mixing of new and old batteries, and the capacity expansion is simple
- Intelligent voltage sharing control, support the number of lithium module differentiation and hybrid
Applications:
| • Uninterrupted power supplies • Security & fire alarm systems • Laboratory & test equipment • Monitoring equipment • Telecom equipment • Emergency lighting |
• Power tools • Medical equipment • Consumer electronics • Portable equipment • Toys and hobbies • Marine instruments |
|
DET PowerWall Smart Series |
||||
| Model/ Parameters |
DETPW-4860 |
DETPW-48100 |
DETPW-48150 |
DETPW-48200 |
| Basic | ||||
| Normal Voltage [V] | 48/51.2 | 48/51.2 | 48/51.2 | 48/51.2 |
| Normal Capacity [Ah] | 60 | 100 | 150 | 200 |
| Operating Voltage [V] | 45~56 | 45~56 | 45~56 | 45~56 |
| Rated energy [kWh] | 2.9 | 4.8 | 7.2 | 9.6 |
| Battery Type | Li-on（LFP） | Li-on（LFP） | Li-on（LFP） | Li-on（LFP） |
| Ah Efficiency [%] | 99.5 | 99.5 | 99.5 | 99.5 |
| Wh Efficiency [%] | 96 | 96 | 96 | 96 |
| Standard Power [kW] | 2.9 | 4.8 | 4.8 | 4.8 |
| Recommended Charging current [A] | 30 | 50 | 50 | 50 |
| Maximum Discharging current [A] | 70 | 100 | 100 | 100 |
| Dimension(L*W*H) [mm] | 400*530*120 | 400*600*200 | 400*600*200 | 400*600*200 |
| Weight [Kg] | 30 | 45 | 53 | 89 |
| Communication | ||||
| Battery to Inverter | RS485/CAN 2.0 | RS485/CAN 2.0 | RS485/CAN 2.0 | RS485/CAN 2.0 |
| Battery to Battery/BMS | RS485 | RS485 | RS485 | RS485 |
| WIFI Application | Optional | Optional | Optional | Optional |
| Capacity Indicator | 4LED (25%, 50%, 75%, 100%) | |||
| Switch ON/OFF | Button | Button | Button | Button |
| Environment | ||||
| Operating Temperature [℃] | -10 to 55 | -10 to 55 | -10 to 55 | -10 to 55 |
| Relative Humidity [%] | 5 to 95 | 5 to 95 | 5 to 95 | 5 to 95 |
| Altitude [m] | Below 2000 | Below 2000 | Below 2000 | Below 2000 |
| Cycle Life [80% DOD] | > 5000 Cycles | > 5000 Cycles | > 5000 Cycles | > 5000 Cycles |
| Parallel Connection | Max.16pcs | Max.16pcs | Max.16pcs | Max.16pcs |
| Warranty [Year] | 5 | 5 | 5 | 5 |
