New Arrival China 6 Volt Battery Deep Cycle - DET Deep cycle battery – DET Detail:
Technical features:
• 5~8 years design life @ 20°C(68°F) ambient temperature,
• 80% remaining capacity;
• UL Recognized component;
• Proprietary Fixed Orifice Plate Pasting technology applying active materials on both sides of the grid for consistent cell-to-cell performance, higher capacity and uniform grid protection.
• Perfect combination between energy storage performance and reliability;
• Operates at a low internal pressure;
• Low self-discharge rate (less than 3% / month @ 20˚C(68˚F);
• Grid plate construction consisting of a Lead Calcium Tin alloy;
• High impact resistant ABS resin cases and covers;
• Available in V-0 Flame Retardant Material;
• In compliance with IEC 896-2;
• Wide operating temperature range;
• Rechargeable VRLA batteries with an electrolyte retained in a glass mat with a very fine glass fibre structure.
• High-Compression Absorbed Glass Mat technology (AGM) for over 99% recombination efficiency.
Applications:
| • Uninterrupted power supplies • Security & fire alarm systems • Laboratory & test equipment • Monitoring equipment • Telecom equipment • Emergency lighting |
• Power tools • Medical equipment • Consumer electronics • Portable equipment • Toys and hobbies • Marine instruments |
Product detail pictures:
Related Product Guide:
abide by the contract", conforms on the market requirement, joins from the market competition by its good quality likewise as provides more comprehensive and superb support for customers to let them become large winner. The pursue of the company, is definitely the clients' pleasure for New Arrival China 6 Volt Battery Deep Cycle - DET Deep cycle battery – DET , The product will supply to all over the world, such as: Russia, Rome, Greece, More than 26 years, Professional companies from all over the world take us as their long-term and stable partners. We are keeping durable business relationship with more than 200 wholesalers in Japan, Korea, USA, UK, Germany, Canada, France, Italian, Poland, South Africa, Ghana, Nigeria etc.
|
DET PowerWall Smart Series |
||||
| Model/ Parameters |
DETPW-4860 |
DETPW-48100 |
DETPW-48150 |
DETPW-48200 |
| Basic | ||||
| Normal Voltage [V] | 48/51.2 | 48/51.2 | 48/51.2 | 48/51.2 |
| Normal Capacity [Ah] | 60 | 100 | 150 | 200 |
| Operating Voltage [V] | 45~56 | 45~56 | 45~56 | 45~56 |
| Rated energy [kWh] | 2.9 | 4.8 | 7.2 | 9.6 |
| Battery Type | Li-on（LFP） | Li-on（LFP） | Li-on（LFP） | Li-on（LFP） |
| Ah Efficiency [%] | 99.5 | 99.5 | 99.5 | 99.5 |
| Wh Efficiency [%] | 96 | 96 | 96 | 96 |
| Standard Power [kW] | 2.9 | 4.8 | 4.8 | 4.8 |
| Recommended Charging current [A] | 30 | 50 | 50 | 50 |
| Maximum Discharging current [A] | 70 | 100 | 100 | 100 |
| Dimension(L*W*H) [mm] | 400*530*120 | 400*530*200 | 400*530*200 | 400*530*200 |
| Weight [Kg] | 30 | 45 | 53 | 89 |
| Communication | ||||
| Battery to Inverter | RS485/CAN 2.0 | RS485/CAN 2.0 | RS485/CAN 2.0 | RS485/CAN 2.0 |
| Battery to Battery/BMS | RS485 | RS485 | RS485 | RS485 |
| WIFI Application | Optional | Optional | Optional | Optional |
| Capacity Indicator | 4LED (25%, 50%, 75%, 100%) | |||
| Switch ON/OFF | Button | Button | Button | Button |
| Environment | ||||
| Operating Temperature [℃] | -10 to 55 | -10 to 55 | -10 to 55 | -10 to 55 |
| Relative Humidity [%] | 5 to 95 | 5 to 95 | 5 to 95 | 5 to 95 |
| Altitude [m] | Below 2000 | Below 2000 | Below 2000 | Below 2000 |
| Cycle Life [80% DOD] | > 5000 Cycles | > 5000 Cycles | > 5000 Cycles | > 5000 Cycles |
| Parallel Connection | Max.16pcs | Max.16pcs | Max.16pcs | Max.16pcs |
| Warranty [Year] | 5 | 5 | 5 | 5 |
